可安装在任意位置
输入法兰可适配特殊的电机
终生润滑，因此免维护
旋转方向同向
输出轴样式多样
优化转动惯量的锁紧系统
精确啮合
机械安装图
性能参数
| 型号 | 段位 | 减速比 | 容许额定扭矩 Nm | 容许最大扭矩 Nm | 额定输入转速 rpm | 最大输入转速 rpm | 容许径向负荷 N | 容许轴向负荷 N |
| HPF42 | 1段 | 3 | 4.5 | 9 | 3000 | 6000 | 200 | 160 |
| 4 | 15 | 30 | 3000 | 6000 | 200 | 160 | ||
| 5 | 14 | 28 | 3000 | 6000 | 200 | 160 | ||
| 7 | 8 | 16 | 3000 | 6000 | 200 | 160 | ||
| 10 | 5 | 10 | 3000 | 6000 | 200 | 160 | ||
| 2段 | 12 | 18 | 36 | 3000 | 6000 | 200 | 160 | |
| 15 | 18 | 36 | 3000 | 6000 | 200 | 160 | ||
| 16 | 20 | 40 | 3000 | 6000 | 200 | 160 | ||
| 20 | 20 | 40 | 3000 | 6000 | 200 | 160 | ||
| 25 | 18 | 36 | 3000 | 6000 | 200 | 160 | ||
| 28 | 20 | 40 | 3000 | 6000 | 200 | 160 | ||
| 35 | 18 | 36 | 3000 | 6000 | 200 | 160 | ||
| 40 | 20 | 40 | 3000 | 6000 | 200 | 160 | ||
| 50 | 18 | 36 | 3000 | 6000 | 200 | 160 | ||
| 70 | 10 | 20 | 3000 | 6000 | 200 | 160 |
产品接线图
| 型号 | 段位 | 减速比 | 容许额定扭矩 Nm | 容许最大扭矩 Nm | 额定输入转速 rpm | 最大输入转速 rpm | 容许径向负荷 N | 容许轴向负荷 N |
| Pulse/rew | SW1 | SW2 | SW3 | SW4 | ||||
| Default[400] | on | on | on | on | ||||
| 800 | off | on | on | on | ||||
| 1600 | on | off | on | on | ||||
| 3200 | off | off | on | on | ||||
| 6400 | on | on | off | on | ||||
| 12800 | off | on | off | on | ||||
| 25600 | on | off | off | on | ||||
| 500 | off | off | off | on | ||||
| 1000 | on | on | on | off | ||||
| 2000 | off | on | on | off | ||||
| 4000 | on | off | on | off | ||||
| 5000 | off | off | on | off | ||||
| 8000 | on | on | off | off | ||||
| 10000 | off | on | off | off | ||||
| 3600 | on | off | off | off | ||||
| 7200 | off | off | off | off |
